CENTRIX 4 Channel With PoE NVR NVS4-1P

CENTRIX 4 Channel With PoE Network Video Recorder

Model: NVS4-1P



KEY FEATURES
  • 24ch 5M/ 32ch 4M/ 16ch 1080P video input
  • VGA, HDMI simultaneous video output
  • 4-channel input
  • Plug & Play with 4 independent PoE network interfaces
  • Third-party IP cameras supported with ONVIF conformance
  • Support 1-ch HDMI, 1-ch VGA, HDMI at up to 4K(3840×2160) resolution
  • Up to 8 Megapixels resolution recording
  • Support H.265/H.264 video formats
  • Accurate retrieval, instant playback
  • 1 SATA HDD up to 6 TB
  • Support for P2P, UPnP, NTP, DHCP, PPPoE
  • Support for mobile client access
TECHNICAL SPECIFICATIONS
  • Video Input  :  24ch 5M/ 32ch 4M/ 16ch 1080P
  • Playback  :  4ch 5M/ 9ch 4M/ 16ch 1080P
  • IP  VIDEO INPUT  :  4 Ch
  • TWO-WAY AUSIO INPUT  :  1-ch, RCA
  • INCOMING BANDWIDTH  :  40Mbps
  • OUTBOING BANDWIDTH  :  64Mbps
  • REMOTE CONNECTION  :  128
  • HDMI/VGA OUTPUT  :  HDMI: 4K (3840×2160) /30Hz, 1920x1080p /60Hz, 1920x1080p
    /50Hz, 1600×1200 /60Hz, 1280×1024 /60Hz, 1280×720 /60Hz,
    1024×768 /60Hz
    VGA:1920x1080p /60Hz, 1920x1080p /50Hz, 1600×1200 /60Hz,
    1280×1024 /60Hz, 1280×720 /60Hz, 1024×768 /60Hz
  • AUDIO OUTPUT  :  1-ch, RCA
  • RECORDING RESOLUTION  :   8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
  • SYNCHRONOUS PLAYBACK  :  4-ch
  • COMPRESSION  :  H.265/H.264
  • LIVE VIEW/PLAYBACK  :  8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
  • CAPABILITY  :  1 x 4K@30, 3 x 4MP@20, 4 x 1080p@25, 8 x 720p@25, 16 x D1
  • SATA  :  1 SATA interface
  • CAPACITY  :  up to 6TB for each disk
  • NETWORK INTERFACE  :  1 RJ-45 10M/100M self-adaptive Ethernet Interface
  • NETWORK FUNCTION  :  HTTP, TCP/IP, IPV4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS,IP
  • Filter, PPPOE, DDNS, FTP, IP Server, P2P
  • USB INTERFACE  :  Rear panel:2 x USB2.0,Front panel:1XUSB2.0
  • ALARM IN  :  4-ch
  • ALARM OUT  :  1-ch
  • INTERFACE  :  4 independent 100 Mbps PoE network interfaces
  • SUPPORTED STANDARD  :  IEEE 802.3at, IEEE 802.3af
  • POWER SUPPLY  :  48V DC
  • CONSUMPTION W/O HDD  :   5 W
  • POE  :  Max 30W for single port; Max 54W in total ( 13.5W for each )
  • WORKING TEMPERATURE  :  -10°C ~ + 55°C ( +14°F ~ +131°F )
  • WORKING HUMIDITY  :  10% ~ 90%
  • DIMENSION  :  44 × 260 × 240mm ( 1.7″ × 10.2″ × 9.4″ )
  • WEIGHT W/O HDD   :    1.12 Kg ( 2.47 lb )
